GMB2014
Gantry Machining Center GMB2014
2000 × 1400 mm travel6,000 kg table loadBT50 high torque spindle
Gantry type machining center with 2000 × 1400 mm travel for large dies, weldments and energy equipment parts.
2000/1400/800 mm
Travel X/Y/Z
6000 rpm
Spindle
6,000 kg
Table Load
Technical Specifications
- X Axis Travel
- 2000 mm
- Y Axis Travel
- 1400 mm
- Z Axis Travel
- 800 mm
- Spindle Speed
- 6000 rpm
- Spindle Taper
- BT50
- Spindle Motor
- 22 / 30 kW
- Rapid Traverse X/Y/Z
- 12 / 12 / 8 m/min
- Table Size
- 2000 × 1400 mm
- Max. Table Load
- 6,000 kg
- Positioning Accuracy
- ±0.008 mm
- Repeatability
- ±0.004 mm
- Tool Magazine
- 24 / 32 tools, arm type
Standard Configuration
- Moving gantry structure with hardened box ways
- BT50 gear-driven spindle
- Fixed table with T-slots
- Coolant system and chip augers
- Full safety guarding and access platform
- Automatic lubrication
Optional Configuration
- Universal milling head
- Ram type Z axis
- 40 / 60 tool magazine
- Through-spindle coolant
- Fanuc / Siemens control system
- Custom table length
Service & Warranty
12-Month Warranty
Covering machine structure, spindle and control system from commissioning date.
Spare Parts Supply
Common wear parts in stock, dispatched within 48 hours after confirmation.
Remote Diagnosis
Video-guided troubleshooting and parameter support across time zones.
Installation & Training
Overseas commissioning, accuracy verification and operator training available.
Related Machines
Send Inquiry for GMB2014
Include your part material, size, tolerance and monthly quantity so we can confirm the configuration and lead time accurately.
